Socomec DIRIS A-10 w/RS485

Description

• All-in-one power metering and monitoring solution with multi-measurement
• Serial Modbus RS485 communication reports all measurements to Energy Management System
• Easy to use with five pushbuttons to access all measurements
• Backlit LCD display provides clear view of readings
• Equipped with integrated temperature sensor
• Detects wiring errors and automatically corrects CT installation errors
• Class 0.5 in accordance with ANSI C12.20
• Multi-tariff management with selection of one out of two billing tariffs
• Alarms on all electrical values
• DIN-rail mounted
• Current measurement type: AC
• Voltage measurement type: AC
• Frequency rating: 50/60 Hz
• Metering:
• +/- kWh, +/- kvarh, kVAh
• Multi-tariff (2 max)
• Multi-measurement:
• V1, V2, V3, U12, U23, U31, f
• I1, I2, I3, In, ∑P, ∑Q, ∑S, ∑PF
• P, Q, S, PF per phase
• Voltage Ph/N unbalance
• Voltage Ph/Ph unbalance
• Current unbalance
• Number of Digital inputs/outputs: 1 Digital input / 1 Digital output
• Power Quality measurements: THD V1, V2, V3, U12, U23, U31, I1, I2, I3
• Standards:
• UL 61010 Guide PICQ File E257746
• ANSI C12.20
• IEC 61557-12
