CMBE-3-62 Pressure Booster Pump System, 230V

Description

Grundfos CMBE-3-62 is a 230V all-in-one booster pump system with adjustable outlet pressure. It’s compact, time-tested and features an advanced control with built-in pressure tank to prevent water pressure fluctuations due to change in demand or inlet pressure. Installation is easy – simply connect the inlet/outlet pipes, plug the pump into an outlet and set the desired pressure. Grundfos CMBE system is made using high quality materials, including 304 stainless steel housing & impeller – to ensure a lasting, worry-free performance. CMBE-3-62 model is highly versatile and suitable for a wide range of uses – from single and multi-family residential homes, to apartment buildings or hotels and office buildings.
Cross-References:

• Grundfos: 22 BMQE 05B-120, 22 BMQE 10C-190

Features:

• Suitable for single and multi-family homes/apt. buildings, small hotels and office buildings
• Adjustable output pressure via buttons on top panel
• Easy installation – simply connect the piping, connect power and dial the desired pressure
• No fluctuations due to change in water demand or pump starting/stopping
• Quiet, compact, rugged and reliable design
• Includes 5ft cord w/ plug
• High-efficiency ECM motor uses up to 85% less electricity
• Built-in thermal, dry-run and overload protection
• Grundfos Eye LED displays system status for easy troubleshooting
• Grundfos GO compatible
• 5-way fitting w/ integrated check valve, expansion tank and pressure gauge – included
• cULus Listed; NSF/ANSI 61 & 372, MH26400 Listed

Technical Specifications:

• Head Range: 0-220 ft
• Flow Range: 0-25 GPM
• Connections: 1″ FNPT inlet, 1″ FNPT outlet
• Electrical Specs: 200-240V, 50/60 Hz, Single Phase, 0.75 kW max, 6.7-5.6 Amps max
• Motor Rating: 3/2 HP, 360-4000 rpm
• Liquid Temperature Range: 32°F – 140°F
• Max. Ambient Temperature: 131°F
• Max Operating Pressure: 145 psi
• Cut-In Pressure: 7 psi above setpoint
• Enclosure Class: IP55
• Materials: 304 Stainless Steel Housing & Impeller, Cast Iron Flange, Silumin (Alu) Stator Housing, Composite Terminal Box and Fan Cover
• Sound level: 55 db(A)
• Net Weight: 39 lbs
• Dimensions (Depth x Width x Height): 13.60″ x 8.54″ x 17.30″

Warranty:
24 months from the date of installation / 30 months from the date of manufacture
